Pushin Reducing Branch Tee
Regular price
$6.00 USD
Delivery Time
General Delivery Time: 2 working days
Delivery times are a guide and are subject to stock availability
Pushin Reducing Branch Tee – Brass Push-in Tee with Reduced Branch Port
These reducing branch tee push-in fittings have two equal-sized run ports and one smaller branch port, allowing a main air line to feed a smaller branch circuit without the need for a separate reducer. All three ports are push-in for fast, tool-free installation.
Materials & Construction
- Body: Brass
- O-rings: NBR (nitrile rubber)
- Collar: Brass
- Release sleeve: POM (acetal/Delrin)
- Lock claw: Stainless steel
Specifications
- Available sizes (run × branch): 6×4mm, 8×6mm, 10×6mm, 10×8mm, 12×8mm, 12×10mm, 16×10mm, 16×12mm
- Working pressure: 150 psi (10.2 bar)
- Vacuum rating: -29.5 in Hg (-750 mmHg)
- Working temperature: 0°C to +60°C
- Media: Compressed air only (not suitable for other gases or liquids)
Compatible Tubing
Suitable for nylon (PA) tube and polyurethane (PU) tubing.
Typical Applications
- Branching a smaller pilot or instrument line from a larger main supply
- Pneumatic control panels where main and branch circuits use different tube sizes
- Reducing the need for separate inline reducers in complex pneumatic layouts
These are an equivalent to:
Bulk order
| Variant | Quantity | Price | Total |
|---|---|---|---|
|
6mm x 4mm
CDPGT0604N
|
|
||
|
8mm x 6mm
CDPGT0806N
|
|
||
|
10mm x 6mm
CDPGT1006N
|
|
||
|
4mm x 6mm
CDPGT0406N
|
|
||
|
6mm x 8mm
CDPGT0608N
|
|
||
|
8mm x 10mm
CDPGT0810N
|
|
||
|
10mm x 8mm
CDPGT1008N
|
|
||
|
10mm x 12mm
CDPGT1012N
|
|
||
|
12mm x 8mm
CDPGT1208N
|
|
||
|
12mm x 10mm
CDPGT1210N
|
|
||
|
16mm x 10mm
CDPGT1610N
|
|
||
|
16mm x 12mm
CDPGT1612N
|
|
