Pushin Straight Equal Connector – Brass Tube-to-Tube Push-in Union
These straight equal push-in connectors join two lengths of pneumatic tubing of the same diameter in a straight line — no threads required. They are the simplest way to extend a run of tubing or repair a damaged section without cutting into existing fittings.
Materials & Construction
- Body: Brass
- O-rings: NBR (nitrile rubber)
- Collar: Brass
- Release sleeve: POM (acetal/Delrin)
- Lock claw: Stainless steel
Specifications
- Tube sizes: 4mm, 6mm, 8mm, 10mm, 12mm (equal both ends)
- Working pressure: 150 psi (10.2 bar)
- Vacuum rating: -29.5 in Hg (-750 mmHg)
- Working temperature: 0°C to +60°C
- Media: Compressed air only (not suitable for other gases or liquids)
Compatible Tubing
Suitable for nylon (PA) tube and polyurethane (PU) tubing.
Typical Applications
- Extending pneumatic tubing runs
- Repairing or splicing damaged tubing sections
- Joining tubing from different reels in long pneumatic circuits
- General compressed air plumbing in industrial and workshop environments
These are an equivalent to:
Bulk order
| Variant | Quantity | Price | Total |
|---|---|---|---|
|
4mm
CDPUC04N
|
|
||
|
6mm
CDPUC06N
|
|
||
|
8mm
CDPUC08N
|
|
||
|
10mm
CDPUC10N
|
|
||
|
12mm
CDPUC12N
|
|
||
|
14mm
CDPUC14N
|
|
||
|
16mm
CDPUC16N
|
|
