PN16 Stainless Steel Ball Valve complete with Single Acting Actuator
Regular price
£214.66 GBP
Regular price
£296.22 GBP
Sale price
£214.66 GBP
Delivery Time
General Delivery Time: 2 working days
Delivery times are a guide and are subject to stock availability
Single Acting PN16 SS Ball Valve
Actuated ball valve consisting of a PN16 flanged stainless steel firesafe and anti-static full bore ball valve with CF8M stainless steel body and ball, TFM1600 Seats (for manual version see here). Fitted with a Haitima aluminium single acting pneumatic rack and pinion actuator.
What are the main features?
The main characteristics for the assemblies are:
- PN16 Flanged ends
- Firesafe and anti-static ball valves
- Single acting pneumatic actuators, air to open, spring to close (we can supply as air to close, spring to open on request)
- 1/4" BSP Pilot air connections
- Maximum working pressure 16bar
- Working temperature range -20°C to +90°C
What approvals/standards?
The ball valve is certified Firesafe to API607
The actuators are certified to ATEX EXII2GDcT
Certificates can be supplied on request
What Accessories are available?
We offer a range of accessories for our pneumatic actuated valve assemblies such as:
These are an equivalent to:
Bulk order
| Variant | Quantity | Price | Total |
|---|---|---|---|
|
1/2" (DN15)
AKHSA16SS04
|
|
||
|
3/4" (DN20)
AKHSA16SS05
|
|
||
|
1" (DN25)
AKHSA16SS06
|
|
||
|
1.1/4" (DN32)
AKHSA16SS07
|
|
||
|
1.1/2" (DN40)
AKHSA16SS08
|
|
||
|
2" (DN50)
AKHSA16SS09
|
|
||
|
2.1/2" (DN65)
AKHSA16SS10
|
|
||
|
3" (DN80)
AKHSA16SS11
|
|
||
|
4" (DN100)
AKHSA16SS12
|
|
||
|
5" (DN125)
AKHSA16SS13
|
|
||
|
6" (DN150)
AKHSA16SS14
|
|
||
|
8" (DN200)
AKHSA16SS16
|
|
